Coldroom Doors / PVC Rapid Roll Doors

Our range of 'PVC Rapid Roll' & 'Fold up' Door:

Chiller & Freezer Applications
Bespoke made to measure.

Use

  • Rapid Roll-Up doors motorized to install for indoor use. Suitable for installation throughout the Logistic, Pharmaceutical, Automobile and Food Production sectors
  • For use in areas that require rapid traffic manoeuvres.

Advantages

  • Certified door class 2, CE marked, supplied with all necessary safety elements.
  • Guides and lintel in Anodized Aluminium. Consoles, feet and screws in stainless steel.
  • Quick installation and easy programming. Highly reliable. Low maintenance.

Technical Features

Motors:

  • The motor has been manufactured & tested in agreement to the norm DIN_EN 12453 for ‘Industrial, Commercial and garage doors.

Control Panel:

  • Digital door position control. Standard dual contact model
  • Robust mechanical contact block.
  • High quality terminal set for external connections.
  • Protective box IP65 in ABS plastic for positive temps.
  • PVC blade 950g/m2, 1mm thickness, with high strength nylon fabric interlinings.

Safety

  • Guide with integrated photoelectric cell. Safety edge with wireless system accomplishing current standards (20kg static pressure/ 40kg dynamic pressure) according to UNE-EN 12453:2000.

Options

  • Vision Windows
