Do you need...
Hinged Doors?

Our range of Hinged Door:

Chiller & Freezer Applications
Standard sizes or Bespoke made to measure.

USE

  • Hinged Doors suitable for Coldrooms (+0ºC) Chilling and (- 20ºC) Freezing.
  • Suitable for installation in any type of commercial premises, Industrial sector, Hospitality, Supermarkets, Hotels & Restaurants.

ADVANTAGES

  • Quick, simple installation. High degree of insulation.
  • Robust and energy efficient under intensive use.
  • Available in a variety of finishes to meet all clients’ needs.

TECHNICAL FEATURES

  • Frame: Extruded Aluminium with Double Thermal Break
  • Freezer Doors fitted with heating resistances
  • Easy to open both interior & exterior
  • Metal fittings: Grey composite material
  • Hinges: Vertical Hinges (Rising butt hinge for doors with forklift ramp)
  • Injected Polyurethane insulation 40-45 kg/m3
  • Guaranteed air tightness, Durable EPDM seal
  • Finishes: Lacquered, Stainless steel, PVC Steel (Plastisol), or FRP (Fibre-glass reinforced polyester)
  • Lock with key

OPTION:

  • Vision Window, Panic Bar, Stainless steel protection
